Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS

Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS

  • Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
  • Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
  • Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
  • Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
  • Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
  • Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS
Product Details:
Place of Origin: China
Brand Name: Effon
Certification: CE,ROHS, FCC
Model Number: TS20
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: 1pcs into a retail box
Delivery Time: 1-7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 500000pieces per month
Contact Now
Detailed Product Description
Type: Supermarket 2d Manufacturer Price Long Auto Sensor Distance Desk Top Barcode Scanner CE FCC ROHS Interface Type: USB
Scan Element Type: CMOS Application Scenario: Bar Code Payment, Group Purchase Verification, Customer Service Desk And Other Mobile Phone Barcode Verification Scenarios
Barcode Type: 1D/2D Resolution: >10mil
Style: Desk Barcode Reader Color: Ivory
Image Sensor: 640~480 CMOS Storage Temperature: -40°C - +70°C
High Light:

fixed mount barcode reader

,

desktop barcode scanner

Supermarket 2d manufacturer price long auto sensor distance desk top barcode scanner CE FCC ROHS



TS20 desktop barcode scanner allows you to reliably read all 1D barcodes and PDF417, Data Matrix and QR Code on various shapes and surfaces. In addition, it has a bigger scanning window, which allows for reading from e.g. tablet devices and widescreen smartphones.Designed primarily for applications like electronic tickets/coupons, mobile marketing and office automation.



Features:

Excellent screen code reading performance:

Using self-developed core decoding technology, you can quickly recognize Read the screen barcodes of various types of foils



Scattering fill light:
Imitating the natural light source, the light is soft, the illumination is even, and the contrast is bright and dark.Small, you can quickly read low-light screen barcodes.



Success indicator feedback:
When the reading is successful, the device performs feedback on the indicator light to make the heterocyclic ring, Under the circumstances, the status of the scan code is known.



Oversized reading window:
Beyond the window size of the same grade product, it can adapt to the mainstream big screen hand, The machine is close to reading.



Speed reading:
When the scanned barcode approaches the scanning window, the device starts up and advances quickly Reading



Application scenario:
Bar code payment, group purchase verification, customer service desk and other mobile phone barcode verification scenarios



Characteristics:

Image Sensor 640~480 CMOS
Light Source White LED
2D barcodes: PDF417, Data Matrix, QR Code
1D barcodes:EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar (RSS-Expand, RSS-Limited, RSS-14), Code 39, Code 11, MSI-Plessey, Plessey
Resolution >10mil
Interface USB
Scan Window 82mm~64mm

Dimensions (L x W x H) 100.3×120.3×102.8mm
Operating Temperature -20°C - +60°C
Storage Temperature -40°C - +70°C
Humidity 5% - 95% (non-condensing)







Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS 0Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS 1



Supermarket Fixed Mount Barcode Scanner / Desktop Barcode Reader CE FCC ROHS 2
