Wearable PDA Barcode Scanner With Bluetooth Adapter

Wearable PDA Barcode Scanner With Bluetooth Adapter

  • Wearable PDA Barcode Scanner With Bluetooth Adapter
  • Wearable PDA Barcode Scanner With Bluetooth Adapter
  • Wearable PDA Barcode Scanner With Bluetooth Adapter
  • Wearable PDA Barcode Scanner With Bluetooth Adapter
  • Wearable PDA Barcode Scanner With Bluetooth Adapter
  • Wearable PDA Barcode Scanner With Bluetooth Adapter
Wearable PDA Barcode Scanner With Bluetooth Adapter
Product Details:
Place of Origin: China
Brand Name: Effon
Certification: CE,ROHS, FCC, IP65
Model Number: EF02
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: 1pcs into a retail box,OEM box is accepted (According to customer request)
Delivery Time: 1-7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 500000 pieces per month
Contact Now
Detailed Product Description
Material: TPU+PC Product Name: Wearable PDA Barcode Scanner With Bluetooth Adapter For PC Warehouse EF02+WT04
Battery Capacity: 550mah Compatibility: IOS , Android, Windows Smartphones Or PC
Application: Logistics Industry , Store Inventory , Libary , Hospital Ect Superiority: IP65 Rugged Outer Case
Connector: Magnetic Connector Feature: With Battery Charger
High Light:

Wearable PDA Barcode Scanner


finger barcode scanner bluetooth


wearable ring scanner

Wearable PDA Barcode Scanner with Bluetooth Adapter for PC warehouse EF02+WT04


EF02+WT04 wearable ring scanner pda enable operator to move package , products and materials, helping to increase more efficiency, It is very comfortable to wear it in whole working day, with high performance laser scan engine, even poor printed barcode can be read.


Wearable PDA Barcode Scanner With Bluetooth Adapter 0



EF02 Feature:


1. Zebra scan engine for 2d 1d barcodes
2. Supporting Android & IOS & Windows
3. 550mAh replaceable & rechargeable battery for more than 12 hours working time
4. Optional charger & charger with bluetooth adapter function
5. 1.2m drop test 200 times
6. NFC connction


Wearable PDA Barcode Scanner With Bluetooth Adapter 1





WT04 Feature:


CPU:Quad core 2.0GHz
Operation System:Android 9.0
ROM+RAM:3GB+32GBPower supply: non detachable 3300mah lithium ion rechargeable battery, 500 cycles, capacity greater than 80%
Interface / communication :Type-C
Vibration motor:Yes
Audio: built in speaker, 8 Ω 1W * 1, built-in dual microphone


Wearable PDA Barcode Scanner With Bluetooth Adapter 2



Product name Wearable Ring 2D Scanner
Model name EF02







Wearable PDA Barcode Scanner With Bluetooth Adapter 3

Length:55.0mm, Width: 39.2mm, Height:51.2mm

Weight 65grams
Electrical Power: DC5V Typical: 300mA DC5V
Data storage 100KB for offline mode: 6000 15 bytes barcodes(Other flash is optional).
Working mode Bluetooth mode, offline mode and RS232 mode(optional)




Scanner performance

Sensor Type: Laser Diode 650nm

Scanner Angle: ±40°,±45°,±35°(skew, pitch, Roll)

Scan Rate: 104(±12)scans/sec(bidirectional)

Contrast: ≥20%

Decode Speed:104 scans per second






Battery power


Internal Battery: Rechargeable 550mAh Li-ion Battery, Standby 30 days, working time after full charge with good decode as below:


Continuous trigger

scanning interval

Decoding number Working time
1S 20000 5.6hours
5S 7100 9.8hours
10S 4600 12.8hours









Charge time: About 2 hours











































Basic Characteristics
Model Name WT04
OS CPU Android 5.1 Quad-Core 1.2GHz
Display 4.0 inch TFT-LCD WVGA (480×800) color screen
Panel Support Multiple finger touch, gloves touch.
Internal storage



Dimensions 118mm×91mm×33mm
Weight 273g(Included battery and wristband)

Context Button,Home Button,Back Button,2 User

definable buttons(F1, F2) , Button,power button

Main Battery Rechargeable 3.8V 2850 mAh
Charging time No more than 4 hours
RTC Battery Real time clock battery


Radio Communication
Wifi 802.11 a/b/g/n wireless communication
Bluetooth Bluetooth 4.0 HS low energy
Chinese version 4G TDD-LTE:Band 38/39/40/41
FDD-LTE:Band 1/3
2G GSM/EDGE:850/900/1800MHz
International Version 4G TDD-LTE:Band1/2/3/4/5/7/8/20/28A/28B



2G GSM/EDGE:850/900/1800/1900MHz


Expansion and Peripherals
Camera 8MP camera with LED flash and auto-focus function;Support camera scanning
Slot mi cro SD/TF,Mi cro SIM
Interfaces 3.5mm Audio port, 9PinMagnetic pogo pin(With USB and charging functions, Support wired scanner)
Audio Loadspeaker, Mi crophone
Standard Accessories Power adaptor,USB-Magnetic pogo pin data cable,Instructions , Wristband
Optional Accessories Battery charger, ring scanner


User Environment
Operating Temperature -10℃~ 50℃
Storage Temperature -20℃~ 70℃
Humidity 5%RH- 95%RH (non-condensing)
Drop Durability 1.5m
Detailed Images
Wearable PDA Barcode Scanner With Bluetooth Adapter 4
Wearable PDA Barcode Scanner With Bluetooth Adapter 5







Q1. What's your main products ?
- Laser Barcode Scanner - Image Barcode Scanner - Thermal Receipt Printer
- Dot -matrix Receipt Printer - Bluetooth Printer - Cash Register Drawer

Q2. Are you a manufacturer?
Yes, our factory located in ShenZhen .

Q3. Do you have stock products to sell?
Yes, and we also work on OEM /ODM orders, customized your brand & label as your requiment;

Q4.What's the time of delivery ?
It's subject to your order quantity and our production schedule . Usually , 3-5 working days for sample, 12-15 working days for mass production after receipt of payments .

Q5. What information should I let you know if I want to get a quotation?
- The type you need, if possible, the specific product name
- Color & Interface
- Quantity of order
- Market of country If possible, let us know if you have any experience on barcode scanners business

Q6. Can I get a sample? And how can I get it? How many days will samples be finished?
Yes, samples can be provided , but to be paid by customers. Sample fee will be in formal order. Most of samples are in stock, it takes 3-6 days by express delivery.

Q7. Do you inspect the finished products?
Yes, each step of production and finished products will be carried out inspection by QC department before shipping.

Q8. What advantage do you have?
1.Full rang of barcode scanner products & Independent research and development department,Supply OEM.
2. We are a manufacturer, and it ensures we have the ability to carry out the production schedule for punctual delivery.
3. Strict QC. For each order, strict inspection will be carried out by the QC department before shipping,
4. Certificates: Kinds of Invention Patents & CE&FCC& ROSH&ISO900:2008 and so on;



Welcome to inquire!
