MS4100 Corded 2D Barcode Reader Scanner for Ticket Checking, Access Control
MS4100 Auto Scaning barcode reader scanner can be used for medical care kiosk /health checking kiosk/health care kiosk soulution. MS4100 is new generation barcode scanner, with fixed mount and compact design, its suitable for all kinds of Kiosk, ATM, ticket terminal, medical device , access control machine etc.
Features and benefits:
l Fast speed sensor
l Industrial leading scan platform
l High speed, Omni directional scanning
l Read all mainstream 1D/2D barcodes
l Read barcode off cell phone screens
l Miniature- easy to integrate
l Extremely easy to use
l Support RS232 and USB interface
|Voltage and Current:
||5 VDC +/-10% @ 400 mA
||640 pixels (H)x 480 pixels (V)
||Aiming: 617 nm LED; illumination: 6500K LED
|Field of View:
||40° (H) x 26° (V)
|Roll / Pitch / Yaw:
||360°, ±65°, ±60°
||25% minimum reflective difference
|Symbology Decode Capability
||UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon Extended Code, Code128, GS1-128, ISBT 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants, Korean 3 of 5, ISBT Concat
||PDF417, MicroPDF417, Composite Codes,Data Matrix, Maxicode, QR Code, MicroQR, Aztec
||up to 25 in. (63.5 cm) per second
||32° to 122° F / 0° to 50° C
||-40° to 158° F / -40° to 70° C
||5% to 95%, non-condensing
||Withstands 10Gs 0.06" double amp
|Ambient Light Immunity:
||Immune to normal lighting up to 1600 Lux. Immune to sunlight up to 86,000 Lux.
|Symbol & Density
|Code 39 (5 mil)
|100%UPCA (13 mil)
|Code 39 (20 mil)
|QR Code (20mil)
|Resolution 1D Code 39
|Resolution 2D Data Matrix
|Performance may be impacted by bar code quality and environmental conditions
Healthcare, Mobile coupon or ticketing (event, airline, cinema, etc), Pharmacy, Patrol Vehicles, Retail, Lottery, Banking, etc.
